- Porsche 955 Cayenne 3.2L V6 2003-06
- Porsche 955 Cayenne S 4.5L V8 2003-06
- Porsche 955 Cayenne Turbo 4.5L 2003-06
- Porsche 955 Cayenne Turbo S 4.5L 2006>>
- Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
- Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
Fits:
Porsche 955 Cayenne 2003-06 (I1BK)
chassis 9P4LA 01526>> onwards
chassis 9P4LA 48416>> onwards
chassis 9P4LA 83740>> onwards
Porsche 957 Cayenne 2007-10 (I1BK)
* I1BK - Air suspension with levelling system and height adjustment (PASM)
Click 'Zoom in' for large parts diagram.
Diagram ref no 3
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
95533107721
The product you are viewing cross references to these numbers
- Porsche 955 Cayenne 3.2L V6 2003-06
- Porsche 955 Cayenne S 4.5L V8 2003-06
- Porsche 955 Cayenne Turbo 4.5L 2003-06
- Porsche 955 Cayenne Turbo S 4.5L 2006>>
- Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
- Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
Air Suspension Compressor
Restore correct operation of the air suspension system with
this OE Match Air Suspension Compressor. The compressor supplies the pressurised air required to
raise the vehicle and maintain the selected suspension height. A weak or failed
compressor can cause slow height adjustment, suspension warning messages or
prevent the vehicle from reaching the correct ride height.
Fits:
- Porsche 955 Cayenne 3.2L V6 2003-06
- Porsche 955 Cayenne S 4.5L V8 2003-06
- Porsche 955 Cayenne Turbo 4.5L 2003-06
-
Porsche 955 Cayenne Turbo S 4.5L 2006>>
*retrofit - requires clamp (99951245700) and pressure line (95535805501) - Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
-
Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
* I1BK - Air suspension with levelling system and height adjustment (PASM)
Diagram ref no 1
What Does the Air Suspension Compressor Do?
The compressor is the main source of air pressure for the Cayenne air suspension system. It draws in and compresses air before supplying it to the suspension system, where it is used to inflate the air springs.
A correctly functioning compressor helps:
- Maintain the correct vehicle ride height
- Raise and lower the suspension
- Supply pressure to the air suspension system
- Compensate for changes in vehicle load
- Maintain correct suspension operation
Why Do Air Suspension Compressors Fail?
Air suspension compressors naturally wear over time, particularly if they are required to run more frequently than normal.
Common causes include:
- Internal compressor wear
- Overheating from excessive operation
- Worn piston seals
- Moisture or contamination
- Electrical motor failure
- Damaged wiring or connections
- Air leaks elsewhere in the suspension system
- General age-related deterioration
An air leak can cause the compressor to run excessively as it repeatedly attempts to restore system pressure. This can eventually overheat and damage an otherwise serviceable compressor.
When Should the Air Suspension Compressor Be Replaced?
Replacement should be considered if:
- The vehicle is slow to raise
- The suspension does not reach the selected height
- The compressor runs excessively
- The compressor becomes unusually noisy
- Air suspension warning messages appear
- The vehicle remains too low
- Diagnostic testing identifies insufficient compressor pressure
- The compressor motor no longer operates
Before fitting a replacement compressor, the complete air suspension system should be checked for leaks. Installing a new compressor without correcting an existing leak can cause the replacement unit to fail prematurely.
Important Air Suspension Checks
If the Cayenne drops in height while parked, the compressor may not necessarily be the cause.
Air springs, air lines, valve blocks and connections should be inspected for leaks. The compressor relay, fuse and electrical supply should also be checked when diagnosing a non-operating compressor.
Porsche Cayenne 955 & 957 Air Suspension Compressors
The air suspension system fitted to Porsche Cayenne 955 and 957 models provides automatic ride-height control and allows the suspension height to be adjusted according to driving conditions.
As these vehicles age, compressors, air springs, valve blocks and air lines can deteriorate. A weak compressor may struggle to produce sufficient pressure, resulting in slow suspension operation, incorrect ride height or suspension warning messages.
When diagnosing Porsche Cayenne air suspension problems, checking the complete system for leaks is particularly important. A leaking air spring or connection can make the compressor work continuously and significantly shorten its service life.
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
95535890105
The product you are viewing cross references to these numbers
- Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
- Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
- Porsche 958 Cayenne V6 3.6L Petrol (300Hp) 2010-17
- Porsche 958 Cayenne V6 3.0L Diesel (245Hp) 2010-17
- Porsche 958 Cayenne S V6 3.0L Hybrid (380Hp) 2010-17
- Porsche 958 Cayenne S V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne S V8 4.2L Diesel (382Hp) 2010-17
- Porsche 958 Cayenne GTS V8 4.8L Petrol (400Hp) 2010-17
- Porsche 958 Cayenne Turbo V8 4.8L Petrol (500Hp) 2010-17
- Porsche 958 Cayenne Turbo S V8 4.8L Petrol (550Hp) 2010-17
- Porsche 970.1 Panamera V6 3.6L 2WD 2009-13
- Porsche 970.1 Panamera 4 V6 3.6L 4WD 2009-13
- Porsche 970.1 Panamera S V8 4.8L 2009-13
- Porsche 970.1 Panamera 4S V8 4.8L 2009-13
- Porsche 970.1 Panamera GTS V8 4.8L 2011-13
- Porsche 970.1 Panamera Turbo V8 4.8L 2009-13
- Porsche 970.1 Panamera Turbo S V8 4.8L 2009-13
- Porsche 970.1 Panamera Diesel V6 3.0L 2011-13
- Porsche 970.2 Panamera V6 3.6L 2WD (310Hp) 2014-16
- Porsche 970.2 Panamera 4 V6 3.6L 4WD (310Hp) 2014-16
- Porsche 970.2 Panamera S V6 Turbo 3.0L 2WD (420Hp) 2014-16
- Porsche 970.2 Panamera S V6 Turbo 3.0L 2WD Executive 2014-16
- Porsche 970.2 Panamera 4S V6 Turbo 3.0L 4WD (420Hp) 2014-16
- Porsche 970.2 Panamera 4S V6 Turbo 3.0L 4WD Executive 2014-16
- Porsche 970.2 Panamera GTS V8 4.8L 4WD (440Hp) 2014-16
- Porsche 970.2 Panamera Turbo V8 4.8L (520Hp) 2014-16
- Porsche 970.2 Panamera Turbo V8 Executive 2014-16
- Porsche 970.2 Panamera Turbo S V8 4.8L 2014-16
- Porsche 970.2 Panamera Diesel V6 3.0L (250Hp) 2014-16
Summary OE Match air suspension valve block for Porsche 970 Panamera and Cayenne 9PA / 92A models. This replacement valve block helps control air distribution within the suspension system, supporting correct ride height adjustment and air suspension operation. It is designed to match the original-style fitment and function, helping restore correct air flow control between the compressor, reservoir, and air suspension struts.
Fits:
Porsche Cayenne (9PA/92A), 2010-2016
Porsche Panamera (970) excluding hybrid, 2013-2018
Download the detailed installation instructions.
Diagram ref no 5
The valve block directs and regulates compressed air within the suspension system. It helps control air flow to each suspension circuit, allowing the vehicle to raise, lower, and maintain the correct ride height as required by the air suspension control system.
Functions
• Replaces the air suspension valve block
• Controls air distribution within the suspension system
• Helps regulate ride height adjustment
• Supports correct operation of air suspension struts
• Helps maintain even vehicle level and suspension response
• Suitable for air suspension fault repair and diagnosis
• OE Match replacement for Porsche air suspension service.
Why Replace This Part?
Air suspension valve blocks can fail due to internal leakage, worn seals, moisture contamination, corrosion, compressor debris, electrical faults, or age. A faulty valve block can cause uneven ride height, slow lifting, suspension warning messages, air leaks, compressor overrun, or one corner of the vehicle dropping after parking. Replacing the valve block helps restore correct air suspension pressure control and vehicle levelling.
When to Replace This Part
• Air suspension warning messages are present
• The vehicle drops on one or more corners when parked
• Ride height adjustment is slow, uneven, or not working
• Air leaks are found at or near the valve block
• Compressor runs too often or for too long
• Suspension does not hold the selected height
• Air suspension diagnostics indicate valve block failure.
Where it fits on the car
This valve block fits within the air suspension pneumatic control system on Porsche 970 Panamera and Cayenne 9PA / 92A models. Exact location can vary depending on model and suspension layout.
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
97035815304
The product you are viewing cross references to these numbers
- Porsche 955 Cayenne 3.2L V6 2003-06
- Porsche 955 Cayenne S 4.5L V8 2003-06
- Porsche 955 Cayenne Turbo 4.5L 2003-06
- Porsche 955 Cayenne Turbo S 4.5L 2006>>
- Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
- Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
Sold each.
Fits:
For cars with option code I1BK - Air suspension with levelling system and height adjustment (PASM)
Porsche 955 Cayenne 2003-06
Porsche 957 Cayenne 2007-10
Click 'Zoom in' for large parts diagram.
Diagram ref no 3
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
95535873002
The product you are viewing cross references to these numbers
- Porsche 955 Cayenne 3.2L V6 2003-06
- Porsche 955 Cayenne S 4.5L V8 2003-06
- Porsche 955 Cayenne Turbo 4.5L 2003-06
- Porsche 955 Cayenne Turbo S 4.5L 2006>>
- Porsche 957 Cayenne 3.0L Diesel 2007-10
- Porsche 957 Cayenne 3.6L 2007-10
- Porsche 957 Cayenne S / GTS 4.8L 2007-10
- Porsche 957 Cayenne Turbo / Turbo S 4.8L 2007-10
Fits:
Porsche 955 Cayenne 2003-06 (I1BK)
chassis 9P4LA 01526>> onwards
chassis 9P4LA 48416>> onwards
chassis 9P4LA 83740>> onwards
Porsche 957 Cayenne 2007-10 (I1BK)
* I1BK - Air suspension with levelling system and height adjustment (PASM)
Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.
95534107
The product you are viewing cross references to these numbers
